MSBR Series 11 Mediant 500 MSBR
Hardware Installation Manual 1. Introduction
1 Introduction
This document provides a hardware description of the Mediant 500 MSBR (hereafter
referred to as device) and step-by-step procedures for mounting and cabling the device.
The device supports the following interfaces:
Multiple WAN:
• Single Gigabit Ethernet copper (10/100/1000Base-T) unshielded twisted pair
(UTP) interface port
• Dual-mode of 1.25 Gbps Optical Fiber Small Form-Factor Pluggable (SFP)
• ADSL2+ / VDSL2
• SHDSL
• 3G Cellular WAN access (primary or backup) using a USB modem
Four Gigabit Ethernet (10/100/1000Base-T) LAN ports
Two USB ports for an optional, 3G cellular WAN modem and/or USB storage services
Serial console port (RJ-45) for device management
(Optional, customer-ordered) Single ISDN PRI (E1/T1) port
(Optional, customer-ordered) Two BRI ports, supporting up to four voice channels as
well as PSTN fallback
(Optional, customer-ordered) Four FXS ports and four FXO ports, or eight FXS ports
only
Note:
• Hardware configurations may change without notice. Currently available hardware
configurations are listed in AudioCodes Price Book. For further enquiries, please
contact your AudioCodes sales representative.
• The SFP module can be used for WAN fiber-optic interface or WAN copper interface.
• For information on configuring the device, refer to the device's User’s Manual.
