Hardware Installation Manual 5. Cabling the Device
5.2.4 SHDSL WAN Cabling
The device provides support for SHDSL interfaces. The SHDSL interfaces are provided by
two RJ-45 ports, where each physical port has four wire-pairs, supporting up to four SHDSL
WAN ports.
Warning:
• The device does not include primary telecom protection! When the DSL telephone
lines are routed outside the building, additional protection - usually a 350V three-
electrode Gas Discharge Tube (GDT) as described in ITU-T K.44 - must be provided
at the entry point of the telecom wires into the building (usually on the main
distribution frame / MDF), in conjunction with proper grounding. The center pin of the
GDT (MDF grounding bar) must be connected to the equipotential grounding bus bar
of the Telecommunication room.
• To protect against electrical shock and fire, use a minimum 26-AWG wire to the
connect DSL port to the network.
Note: SHDSL interface is a customer ordered item.
SHDSL port specifications:
 Conforms to ITU G.991.2 Annexes A, B, E, F and G SHDSL
 Up to 5,696 Kbps over a single wire pair
 Up to 22,784 Kbps over four wire pairs bonding, according to SHDSL.bis (ITU G.991.2
Annexes F, G)
 EFM and ATM support
 Wetting current support on the CPE side, according to G991.2
 Supports both Central Office (CO) and CPE (wetting current on CO - excluded)
 TC-PAM 16/32 line code
