Version 5.2/5.4 77 January 2009
Troubleshooting Guide 14. Management Utilities
14 Management Utilities
This section discusses AudioCodes' proprietary management tools that can be used for
debugging:
''CPTWizard'' on page 77
''BootP/TFTP Server'' o
n page 77
14.1 CPTWizard
The Call Progress Tones Wizard (CPTWizard) is an AudioCodes proprietary application
designed to facilitate the provisioning of FXO devices, by recording and analyzing Call
Progress Tones (CPT) generated by any PBX or telephone network. These CPT's include
tones such as dial tone, busy tone, ring tone, and reorder tone. The CPTWizard creates
these CPT files in *.dat file format, for loading to the device.
For a full description of the CPTWizard, refer to the Product Reference Manual.
14.2 BootP/TFTP Server
The Bootstrap Protocol allows a host to configure itself dynamically. AudioCode's
proprietary BootP/TFTP Server utility allows you to perform the following:
Assignment of IP address, subnet mask and default gateway IP address to the device.
Provides the name of the software (*.cmp) and configuration (*.ini) files to be loaded to
the device (via TFTP). (BootP also provides the IP address of the TFTP server).
The table below lists the device's default IP addresses:
Table 14-1: Default IP Addresses Per Product
Network Parameter Default Value
IP Address
10.1.10.10:
9 Mediant 1000
9 Mediant 600
9 Mediant 2000 (up to 8 trunks)
9 MP-124
9 MP-11x FXS
9 MP-11x FXS/FXO
10.1.10.10 (trunks 1-8) and 10.1.10.11 (trunks 9-16): Mediant 2000 with
two modules - 16 trunks
10.1.10.11: MP-11x FXO
Subnet Mask 255.255.0.0
Default Gateway IP
Address
0.0.0.0
