AUMA SA Series Operation Instructions

Weights for multi-turn actuators SA 07.2 – SA 16.2 / SAR 07.2 – SAR 16.2
with 3-phase AC motors
Weight
2)
Motor type
1)
Type designation
Actuator
approx. [kg]
46VD...SA 14.6/
SAR 14.6
53AD...
67VD...SA 16.2/
SAR 16.2
83AD...
Refer to motor name plate1)
Indicated weight includes AUMA NORM multi-turn actuator with 3-phase AC motor, electrical con-
nection in standard version, output drive type B1 and handwheel. For other output drive types, heed
additional weights.
2)
Table 4:
Weights for multi-turn actuators SA 07.2 – SA 16.2 / SAR 07.2 – SAR 16.2
With 1-phase AC motors
Weight
2)
Motor type
1)
Type designation
Actuator
approx. [kg]
25VE...SA 07.2/
SAR 07.2
28AE...
25VE...SA 07.6/
SAR 07.6
28AE...
37AC...
28VE...48-4...SA 10.2/
SAR 10.2
31VE...48-2...
40AC... 56-4...
43AC... 56-2...
59VE...SA 14.2/
SAR 14.2
61VC...
63AC...
63VE...SA 14.6/
SAR 14.6
66VC...
Refer to motor name plate1)
Indicated weight includes AUMA NORM multi-turn actuator with 1-phase AC motor, electrical con-
nection in standard version, output drive type B1 and handwheel. For other output drive types, heed
additional weights.
2)
Table 5:
Weights for multi-turn actuators SA 07.2 – SA 16.2 / SAR 07.2 – SAR 16.2
With DC motors
Weight
2)
Motor type
1)
Type designation
Actuator
approx. [kg]
29FN... 63-...SA 07.2/
SAR 07.2
32FN... 71-...
30FN... 63-...SA 07.6/
SAR 07.6
44FN... 80-...
33FN... 63-...SA 10.2/
SAR 10.2
36FN... 71-...
56FN... 90-...
68FN... 71-... / FN... 80-...SA 14.2/
SAR 14.2
100FN... 90-...
13
SA 07.2 – SA 16.2/SAR 07.2 – SAR 16.2 Control unit: electronic (MWG)
AC 01.2 Non-Intrusive HART Transport, storage and packaging

AUMA SA Series Specifications

General

Torque range	10 Nm to 32, 000 Nm
Protection class	IP68
Ambient temperature	+70°C
Voltage	24V DC
Communication	PROFIBUS DP, MODBUS RTU, Foundation Fieldbus
Certifications	ATEX, IECEx, CSA, GOST, SIL
Control	Local, Remote, Bus (PROFIBUS, MODBUS)
