AUMA SA Series Operation Instructions

Please state device type and our order number (see name plate) when ordering spare parts. Only original AUMA spare parts should be used.
Failure to use original spare parts voids the warranty and exempts AUMA from any liability. Representation of spare parts may slightly vary
from actual delivery.
TypeDesignationRef. no.
Sub-assemblyHousing001.0
Sub-assemblyLocal controls002.0
Sub-assemblyLocal controls board002.3
Display face plate002.4
Sub-assemblyPower supply006.0
Sub-assemblyI/O board008.1
Sub-assemblyLogic board009.0
Sub-assemblyRelay board011.1
Option board012.0
Sub-assemblySocket carrier complete with sockets501.0
Pin carrier without pins502.0
Sub-assemblySocket for controls503.0
Sub-assemblySocket for motor504.0
Sub-assemblyPin for controls505.0
Sub-assemblyPin for motor506.0
Sub-assemblyCover for electrical connection507.0
Sub-assemblySwitchgear508.0
Sub-assemblyPadlock509.1
SetFuse kit510.0
Sub-assemblyCover611.0
SetSeal kitS
88
SA 07.2 – SA 16.2/SAR 07.2 – SAR 16.2 Control unit: electronic (MWG)
Spare parts AC 01.2 Non-Intrusive HART

AUMA SA Series Specifications

General

Torque range	10 Nm to 32, 000 Nm
Protection class	IP68
Ambient temperature	+70°C
Voltage	24V DC
Communication	PROFIBUS DP, MODBUS RTU, Foundation Fieldbus
Certifications	ATEX, IECEx, CSA, GOST, SIL
Control	Local, Remote, Bus (PROFIBUS, MODBUS)
