AUMA SAEx 16.2 Operation Manual

Ex marking
Table 1:
Motor for explosion protection (with example /13B1111-)
-1111B31/
Version (actuator with/without actuator controls)
1 = NORM (without actuator controls)
1
Electrical connection
3 = Terminal connection type: KES-Exd
(terminal compartment Ex d flameproof enclosure)
3
Control unit cover
B = Without indicator glas
W = With indicator glas
B
Motor heater
1 = Without motor heater
2 = With motor heater
1
Motor insulation class
1 = Insulation class F
2 = insulation class H
1
Not applicable
Not appliccable
1
Motor type
1 = ADX or VDX: 3-phase AC motor
2 = AEX, ACX, VEX, VCX: 1-phase AC motor
1
Order number
The product can be identified using this number and the technical data as well as
order-specific data pertaining to the device can be determined.
Please always state this number for any product inquiries.
Actuator serial number
Table 2:
Description of serial number (example of 0516UD12345)
UD123451605
Positions 1+2: Assembly in week = week 0505
Positions 3+4:Year of manufacture = 201616
Internal number for unambiguous product identificationUD12345
2.2. Short description
Multi-turn actuator
Definition in compliance with MSS SP-102 [EN ISO 5210]:
A multi-turn actuator is an actuator which transmits to the valve a torque for at least one
full revolution. It is capable of withstanding thrust.
AUMA multi-turn actuators are driven by an electric motor and are capable of withstanding
thrust in combination with output drive type A. For manual operation, a handwheel is
provided. Switching off in end positions may be either by limit or torque seating. Controls
are required to operate or process the actuator signals.
Actuators without controls can be equipped with AUMA actuator controls at a later date.
For more information, please state our order number (refer to actuator name tag).
10
SAEx 07.2 – SAEx 16.2 / SAREx 07.2 – SAREx 16.2
Identification
