AUMA SQEx 12.2 Manual

Name tag
10
SQEx 07.2 -FA10
FA10 Flange size
Order number (commis-
sion number)
The product can be identified using this number and the technical data as well as or-
der-specific data pertaining to the device can be determined.
Please always state this number for any product inquiries.
Ex marking
Table3: Description of the Ex marking with the example of /13B1111
Marking for the explosion protection (with the example of /13B1111)
/ 1 3 B 1 1 1 1
1
Version (actuator with/without actuator controls)
1 = NORM (without actuator controls)
3
Electrical connection
3 = Terminal connection type: KES-Ex d (terminal compartment Ex d flameproof enclosure)
B
Cover of control unit
B = without indicator glass
W = with indicator glass
1
Motor heater
1 = without motor heater
2 = with motor heater
1
Motor insulation class
1 = Insulation class F
2 = Insulation class H
1
Not applicable
without signification
1
Motor type
a = VD. or SD.: 3-phase AC motor
Actuator serial number
Table4: Serial number until 2022, description with the example of 0520NS12345
05 22 NS12345
05 Positions 1+2: Assembly in week = week 05
22 Positions 3+4: Year of manufacture = 2022
NS12345 Internal number for unambiguous product identification
Table5: Serial number as of 2023, description with the example of 0000-00101-2023
00000-00101 - 2023
00000-00101
Serial number of sales article
11-digit internal number for unambiguous product identification
2023 Year of manufacture = 2023

AUMA SQEx 12.2 Specifications

General

Brand	AUMA
Model	SQEx 12.2
Category	Controller
Language	English
