ENGINE MANUAL
IAE50R – AA
5.2.10 Pressure to Fuel Injector
Nominal 3 bar, operation range 2.8 bar to 3.2 bar
Controlled by a pressure regulator.
5.2.11 Lubrication
Lubrication of all bearings and rubbing surfaces is
achieved via two lines from the oil metering unit
driven off the water pump. The flow rate of the
metering unit is calibrated and must not be adjusted.
Use only approved engines oils.
Oil Separator An optional oil separator is recommended. The
separator is to be supplied by the engine installer.
5.2.12 Oil Specification
SILKOLENE Comp 2 Premix
SILKOLENE Classic 2T Premix
CASTROL XR77 (EMPA specification 417478/01)
CASTROL Power 1 Racing 2T (API TC+, JASO FD, ISO EGD)
AEROSHELL Oil Sport Plus2 (API TC)
The use of SILKOLENE Comp 2 Injector is NOT allowed.
