ENGINE MANUAL

IAE50R – AA

E1.01.05 – E

Issue date: 25.Jan.2018

Page: 19-14

Revision no: 9

19.3.2 Rotor cooling air out temperature sensor

The sensor should be mounted as defined in the following figures:

Fig. 20

approx. 10 mm

approx. 5,3 mm

approx. 27 mm

RCAO flange surface

Temp.

Sensor

Temp.

Sensor

Default Chapter2
- Issue Date: 25.Jan.2018 Revision2
