Auta AC-900 - Visualtech System Wiring

6
One access and distribution in cascade
DIGITAL
32
VISUALTECH
4
7
0
1
C
2
PD VISUALTECH FV
COLORS CODE FOR
CAT 5 CABLE
Data cable composed by
4 twisted pair wires
CONNECT A 10K RESISTOR AT
THE END OF EACH RISER
5 WIRES
CALLING WIRES
5H CONTROL MODULE
In old installations 4+n
make a link between all
calling wires and connect
them to negative of the
control module
C/1
C/n
DOOR OPENER
VISUALTECH CONTROL MODULE
DOOR OPENER
PUSH-BUTTON
