Auta AC-900 - Power Supply Distribution

6
Power supply distribution
ALV-3.5A + ATF-12
ATF-98
*The power supply unit ALV-DIGITAL 3.5A does not give A/C current
(R-C). So it has to be installed with and ATF-12 power supply unit
to release the electrical strike & to light the cardholder
POWER SUPPLY
ATF-98
10
UP TO
PHONES
UP TO
MONITORS
20
ALV-3.5A + ATF-12*
40
80
DIGITAL
44
POWER SUPPLY
DISTRIBUTION
ATF-98
ATF-98
DOOR OPENER
DOOR OPENER
CONTROL MODULE
CONTROL MODULE
Do NOT connect the
power supply units
in parallel
WARNING
Do NOT connect the
power supply units
in parallel
WARNING
UP TO 40 DIGITAL COMPACT MONITORS
UP TO 80 DIGITAL COMPACT PHONES
UP TO 40 DIGITAL COMPACT MONITORS
UP TO 80 DIGITAL COMPACT PHONES
UP TO 10 DIGITAL COMPACT MONITORS
UP TO 20 DIGITAL COMPACT PHONES
UP TO 10 DIGITAL COMPACT MONITORS
UP TO 20 DIGITAL COMPACT PHONES
BATTERY
BATTERY
