Auta AC-900 - Video Distribution Per Floor with Auxiliary Monitors or Phones

Video distribution per floor with auxiliary monitors or phones
DIGITAL COMPACT MONITOR
J2 position 1-2 secondary monitor
J2 position 2-3 main monitor
Configure the phone and monitor with the same calling code
DIGITAL COMPACT MONITOR
WARNING
TAKE ALL THE DISTRIBUTORS JUMPERS
OUT UNLESS THE FINAL ONE.
SUPPLY THE DISTRIBUTORS CONNECTING
THEM TO THE + POLE
DIGITAL
39
MONITORS
DISTRIBUTION
GENERAL RISER
+
+ +
L
S3 S4
+
L
S1 S2
S3 S4
L
S1 S2
L
+
++-
-
-
-
+ +++-
-
-
-
Vi Vo Vi Vo
Vi Vo Vi Vo
Vi Vo
Vi Vo
*
*
**
*
* If the installation has less than
40 monitors and the distance is
shorter than 50 mts., the negative
wire of the rise can be supressed
DO NOT TAKE OUT THE
DISTRIBUTOR JUMPER
DVC-4S
TAKE OUT THE
DISTRIBUTOR JUMPER
DVC-4S
DIGITAL COMPACT PHONE
J1 position 2-3 secondary phone
J2 position 2-3 main monitor
Configure the phone and monitor with the same calling code
DIGITAL COMPACT MONITOR
DIGITAL COMPACT PHONE
J1 position 2-3 secondary phone
J2 position 2-3 main monitor
Configure the phone and monitor with the same calling code
DIGITAL COMPACT MONITOR
DIGITAL COMPACT MONITOR
J2 position 1-2 secondary monitor
J2 position 2-3 main monitor
Configure the phone and monitor with the same calling code
DIGITAL COMPACT MONITOR
