Auta AC-900 - Module of Control Coaxial; Twisted Pair; Video Distributor

Description and Material
MODULE OF CONTROL COAXIAL/TWISTED PAIR REF:600005
DIGITAL
9
TWISTED PAIR
c
g
b
a
d
h
a. Connection terminals
b. Configuration switch
c. Camera Twisted pair connector
d. Audio module and camera
connector
e. Illumination of the panel
connector
f. Keyboard module connector
g. Rows connector
h. Columns connector
Codigo
J1
J2
J6J4
CLAP1234
CR
+
Vi
b
Vi
a
Vo
b
a
Vo
RC
J7
J5
e
TWISTED PAIR
Vi
b
Vi
a
Vo
b
a
Vo
IN OUT
VIDEO
f
VIDEO DISTRIBUTOR DV-5H
+
-
Va Vb
Va Vb
Vo1
Vo2
Vi
Va Vb
Twisted Pair connection in the common riser
Negative. Connected to the common negative in
the whole installaton
Video output 1 to the monitors
Video output 2 to the monitors
ELECTRONIC CALL EXTENSION (POLARIZED CALL)
OUTPUT AUXILIARY PUSH-BUTTON
MICRO
LOUD SPEAKER
POSITIVE +24V
OUTPUT 2nd CAMERA
NEGATIVE
INPUT AUXILIARY PUSH-BUTTON FOR CHIME
OUT TWISTED PAIR
MONITOR CONNECTOR
DV-2000 +12V SUPPLY
-
+
2C
Vb
Va Vb Va
AUX.
AD
IN TWISTED PAIR
TWISTED PAIR MONITOR CONNECTOR
MV-D PT "TWISTED PAIR"
Vb
Va
-
+
RC
R
MV-D PT
C
R
MODULO CONTROL / MODULE OF CONTROL
C
CAMARA - CAMERA
ANTIVAHO / ANTI-MIST
PAR TRENZADO / TWISTED PAIR
CONECTOR / CONNECTOR
MV-D PT CAMERA CONNECTOR
Connect the MV-D PT to the J7 terminal of the module
of control ref: 600005
12Vac antimist allimentation
Connect the R-C of the module MV-D PT to the R-C of
the module of control ref: 600005
To make a coaxless installation, we have to use the selected panel with the camera module MV-D PT "Twisted Pair",
we have to use video distributors DV-2000 and digital "Twisted Pair" compact monitors.
Positive. Connected to the common positive in
the whole installaton
TAKE ALL THE DISTRIBUTORS JUMPERS
OUT UNLESS THE FINAL ONE
