Auta AC-900 - Page 56

Video distribution per floor
mm.²
METERS DISTANCE
UP TO 100
UP TO 200
AWG
18
0,5
20
1,00
WIRING SECTION
S1 S2 S3 S4
LL
+
DVC-4S
S1 S2 S3 S4
LL
+
DVC-4S
WARNING
TAKE ALL THE DISTRIBUTORS JUMPERS
OUT UNLESS THE FINAL ONE.
SUPPLY THE DISTRIBUTORS CONNECTING
THEM TO THE + POLE
ANALOG
56
MONITORS
DISTRIBUTION
CALL
7 +24 CT
10
34 12VoVi
CALL
7 +24 CT
10
34 12VoVi
CALL
7 +24 CT
10
34 12VoVi
CALL
7 +24 CT
10
34 12VoVi
CALL
7 +24 CT
10
34 12VoVi
CALL
7 +24 CT
10
34 12VoVi
CALL
7 +24 CT
10
34 12VoVi
CALL
7 +24 CT
10
34 12VoVi
7 +24 CT
10
34
DO NOT TAKE OUT THE
DISTRIBUTOR JUMPER
DVC-4S
TAKE OUT THE
DISTRIBUTOR JUMPER
DVC-4S
