20
Go to the Support application to follow up the
processing progress, see Data Logging on page
72.
Send
Taps it to submit the Data Logging report to the
technical center via the internet.
 To print data in Diagnostics
1. Tap the Diagnostics application button from the MaxiSys Job Menu. The
Print button on the diagnostic toolbar is available throughout the whole
Diagnostics operations.
2. Tap Print and a drop-down menu appears.
a) Print This Page – prints a screenshot copy of the current screen.
b) Print All Page – prints a PDF copy of all displayed data.
NOTE
Make sure the tablet is connected to the computer network, either via Wi-Fi or
LAN, before printing. For more instructions on printing, see Print on page 74 for
details.
 To submit Data Logging reports in Diagnostics
1. Tap the Diagnostics application button from the MaxiSys Job Menu. The
Data Logging button on the diagnostic toolbar is available throughout the
whole Diagnostics operations.
2. Tap the Data Logging button. The button displays blue during the active
recording process.
3. Tap the Data Logging button again to finish recording. A submission form
will display to let you fill in the report information.
4. Tap the Send button to submit the report form via the internet, a
confirmation message displays when sending is successful.
Status Information Bar
The Status Information Bar at the top of the Main Section displays the
following items:
1. Menu Title – indicates the menu subject of the Main Section.
2. VCI Icon – indicates the communication status between the tablet and the
MaxiFlash Elite.
3. Battery Icon – indicates the battery status of the vehicle.
