Figure 6-2 Sample Image Database Screen
1. Toolbar Buttons – used to edit, print and delete the image files. See Table
6-1 Toolbar Buttons in JPG Database on page 70 for detailed information.
2. Main Section – displays the stored images.
Table 6-1 Toolbar Buttons in JPG Database
Returns to the previous screen.
Tap to display the editing toolbar to
print, delete or view image information.
Tap to close the editing toolbar or
cancels file search.
Quickly locates the image file by
entering the vehicle name, test path,
file name or file info.
Tap to open a window displaying and
editing the detail information of the
image.
Tap to print the selected image.
Tap to delete the selected image.
