Automated Logic RC642D User Manual

26
The Run and Error LED's indicate controller and network status.
If Run LED shows...
And Error LED shows...
Status is...
2 flashes per second Off Normal
2 flashes per second 2 flashes,
alternating with
Run
LED
Five minute auto-restart delay
after system error
2 flashes per second 3 flashes,
then off
The controller has just been
formatted
2 flashes per second 4 flashes,
then pause
Two or more devices on this
network have the same
ARC156 network address
2 flashes per second 1 flash per second The controller is alone on the
network
2 flashes per second On Exec halted after frequent
system errors or control
programs halted
5 flashes per second On Exec start-up aborted, Boot is
running
5 flashes per second Off Firmware transfer in progress,
Boot is running
7 flashes per second 7 flashes per second,
alternating with
Run
LED
Ten second recovery period
after brownout
14 flashes per second 14 flashes per second,
alternating with
Run
LED
Brownout
On On Failure. Try the following
solutions:
• Turn the Room Controller
off, then on.
• Format the Room
Controller.
• Download the Room
Controller.
• Replace the Room
Controller.
