The table below shows the editable properties in these built-in control programs:
#1 100% outside air unit
#2 Air source heat pump - reverse to heat
#3 Air source heat pump - reverse to cool
#4 Air source heat pump - intermittent fan - reverse to heat
#5 Air source heat pump - intermittent fan - reverse to cool
#6 Convective/fin tube heater
#7 Fan coil unit - 2-speed fan, modulated or 2-stage cooling and heating
#8 Fan coil unit - 3-speed fan, 2-stage or modulated cooling, 1-stage or modulated heating
#9 Fan coil unit - 3-speed fan, 1-stage or modulated cooling, 2-stage or modulated heating
#10 Fan coil unit - intermittent fan, modulated or 2-stage cooling and heating
#11 Fan coil unit - heat controlled fan, modulated or 2-stage cooling and heating
#12 Unit ventilator
Used in control program
Properties
Units
Default
1
2
3
4
5
6
7
8
9
10
11
12
Setpoints
Unocc Clg Setpt Deg 85 X X X X X X X X X X X X
Occ Clg Setpt Deg 74 X X X X X X X X X X X X
Occ Htg Setpt Deg 70 X X X X X X X X X X X X
Unocc Htg Setpt Deg 55 X X X X X X X X X X X X
Color Band Width Deg 2 X X X X X X X X X X X X
Color Hysteresis Deg 0.5 X X X X X X X X X X X X
PID
Htg P Gain % 20 X X X X X X X X X X X X
Htg I Gain % 2 X X X X X X X X X X X X
Htg D Gain % 0 X X X X X X X X X X X X
Htg PID Interval Sec 60 X X X X X X X X X X X X
Htg PID Ramp Time* Sec 240 X X X X X X X X X X X X
Htg PID Deadband** Deg 0.5 X X X X X X X X X X X X
Clg P Gain % 20 X X X X X X X X X X X
Clg I Gain % 2 X X X X X X X X X X X
Clg D Gain % 0 X X X X X X X X X X X
Clg PID Interval Sec 60 X X X X X X X X X X X
Clg PID Ramp Time* Sec 240 X X X X X X X X X X X
Clg PID Deadband** Deg 0.5 X X X X X X X X X X X
Editable properties
