REP. REPRESENTATION DESCRIPTION LOCATION
3
Label 'Ground connection' or equipotential
bonding.
On the circuit breaker bracket
4
by Automatic Systems
BL229 - 0003 - AS1620-STD/TOLL
Scan this QR Code and
download all the technical
documentation concerning
this product
Scannez ce QR Code et
téléchargez toute la
documentation technique
concernant ce produit
Label with QR Code giving access to the
technical documentation of the product.
On the top plate of the housing.
5
Model
Mfg Date
Phases
Volts
kg
Hz
A
x M
Item
Serial
SN
MADE IN BELGIUM www.automatic-systems.com
230
1
4
85
50/60
Product identification label. On the top plate of the housing.
6
HIGH LEAKAGE
CURRENT
Earth connection essential
before connecting sypply.
Courant de fuite
élevé
Raccordement à la terre
indispensable avant le
raccordement au réseau.
Label 'HIGH LEAKAGE CURRENT'. On the protective cover of the control
board.
7
CHANGER LE BOUCHON
CHANGE PLUG
STOPFEN WECHSELN
STOP VERWISSELEN
CAMBIAR EL TAPÓN
SOSTITUIRE IL TAPPO
Label for changing the transport plug of
the gear motor.
On the protective cover of the control
board.
8
YY-B229-Bxxxx
Product information label, min. version On the control logic;
On the frequency converter;
On the gear motor nameplate.
