10.3. DIMENSIONS OF BL 229 WITH ARTICULATED ARM (OPTION)
Mobile part
Driving part
L
360
872
1052
B
A
Driving part
length (mm)
A
(mm)
B
(mm)
L
(mm)
Round
arm
1030 1995 1840
2500
to
5000
1230 2195 2040
1330 2295 2140
Flat
arm
1000 1972 1810
2200
to
3000
1100 2072 1910
1200 2172 2010
1300 2272 2110
Fig. 41 - Dimensions of BL 229 with articulated arm
