9.2. SPECIFIC TECHNICAL FEATURES
BL 229 BL 229 Toll
Aluminium boom profile Round, Ø84. Oval, section 80 x 53 mm
Opening/Closing time Adjustable between 1,2 and 4 sec. according to
3 profiles :
• Standard
6
• Intermediate
7
• Maximum
8
From 0,6 to 1,7 seconds
Free passage (L) From 2 to 6m
9
From 2,5 to 4m.
BALANCING SPRING, HIS FIXING PARTS, AND ALL ACCESSORIES THAT COULD BE ADDED ON THE BARRIER (BOOM
LIGHT, TIP SUPPORT, FOLDING FENCE …) ARE NOT INCLUDED IN THE MCBF OF 10.000.000 CYCLES.
ALL ELEMENTS THAT ARE NOT PART OF THE WARRANTY MUST BE CONTROLLED PERIODICALLY ACCORDING TO THE
CHAPTER ( CH. 8.3. MAINTENANCE, PAGE 40).
IF THE BARRIER IS USED INTENSIVELY OR IF THE AMBIENT TEMPERATURE OF USE IS HIGH, AUTOMATIC SYSTEMS
RECOMMENDS THE USE OF THE OPTIONAL VENTILATION KIT.
6 - Impact force in accordance with EN 12453.
7 - Impact force in accordance with EN 12453 with the addition of a foam protection under the arm.
8 - The installer must ensure that the installation conforms to the standard, e.g. with dead man operation.
9 - Between 5 and 6 m, a tip support is delivered with the barrier.
44
BL 229
