1. SAFETY WARNINGS
Read this document carefully and in full before using the barrier and keep it in a safe place for future use. Failure
to comply with the instructions in this document may cause damage to the barrier and serious personal injury.
This equipment has been designed to control and manage vehicle access and cannot be applied to any other use without risk
to users or to the integrity of the equipment. Automatic Systems cannot be held responsible for damage caused by improper
use of the equipment.
Putting up a vehicle barrier or an access control obstacle exposes you to liabilities in terms of people’s safety:
• Pedestrian, cyclist and motorcyclist must be banned from accessing the passage where the barrier is. However, if pedestrians
must use this passage, it is mandatory to effectively signal their movement (sound and/or light signal, markings on the
ground, and so on).
• In the countries of the European Union, the EC Machines Directive requires the displaying of the pictogram forbidding
pedestrian access to the danger zone somewhere on the equipment (less than 1 metre upstream and downstream from the
barrier's arm in horizontal position) ( Chap. 5.5, page 12):
BLACK
WHITE
• Any intervention on the equipment must be made by qualified personnel. Any work on this product that is unauthorised or
carried out by an unqualified technician will automatically entail the annulment of the constructor's warranty.
• Personal protective equipment (PPE) must be worn when working on the barrier:
ASSEMBLE THE ARM AND ITS ACCESSORIES BEFORE PERFORMING ANY ELECTRICAL TESTS CHAP. 6.4, PAGE 21
NEVER OPERATE THE BARRIER, EVEN MANUALLY, IF THE LIMIT CAM AND THE END STOP UNITS ARE NOT INSTALLED
PROPERLY. ( REP. K & L, FIG. 14, PAGE 18).
ATTENTION!
LIFT THE ARM BEFORE PERFORMING ANY WORK INSIDE THE HOUSING TO RELEASE THE TENSION IN THE BALANCING
SPRINGS AND PREVENT UNDESIRED MOVEMENTS OF THE DRIVING MECHANISM!
4
BL 229
