8. USE
8.1. COMMISSIONING
Before commissioning, review the procedures described in chapters 6. Installation, 7. Adjustments, 8. Use and 8.3. Maintenance.
The following list can be used as a checklist for commissioning the barrier.
F Anchor the gate to the ground in accordance with the recommendations of the ( Ch. 6. Installation, page 14).
F Attach the arm ( Ch. 6.4. Installation of the arm, page 21).
F Check the proper positioning of the arm in its open position (vertical) and closed position (horizontal). Refer to the
corresponding adjustment if necessary ( Ch. 7.5. Levelling of the boom arm, page 32).
F Adjust the balance of the arm ( Ch. 7.2. Balancing of the boom arm by means of the spring, page 29).
F Connect the inputs an outputs on the control logic.
F Connect the power cables on the terminal blocks.
F Power up the unit, by means of the main switch (Rep. 24, page 9), and wait for the control logic to complete its
initialisation (about 5 seconds).
F The integrated HMI displays the message boot.
F After few seconds, the message run appears and the equipment is ready to use.
Refer to the control unit handbook for the meaning of the various messages displayed on the HMI.
F Proceed to the calibration ( Ch. 7.7. Calibration of the analog sensor, page 35).
THE GATE WILL NOW MOVE TO DETERMINE THE UP AND DOWN POSITION!
F Check the correct configuration of the gate. If needed, adjust the parameters via the maintenance interface.
F Check the proper working of any options and safety measures.
F Carry out some electrical opening and closing tests by using the integrated HMI (Menu > Commands) or by means of the
command mode that is at your disposal (push-button box, transmitter/receiver, etc.
