Arm in vertical position
Spring(s), at rest
Assembly of stops
Gear motor shaft
Connecting rod
Gear motor
1
Fig. 31 - Detail of the screw fixing the
connecting rod onto the gear motor shaft.
Fig. 32 - Gate mechanism in open position
2
Pressure screws
Spiral cam
Analog sensor
3
Fig. 33 - Detail of the screw fixing the gear motor shaft Fig. 34 - Detail of pressure screws fixing the spiral cam
34
