Autonics TK4M User Manual

2 Specifications
22 © Copyright Reserved Autonics Co., Ltd.
Series TK4
Hysteresis
RTD/ Thermocouples Resistor: 1 - 100℃/℉ (0.1 - 100.0℃/℉ ) Variable
Analog: 1 to 100 digits
Proportional Band (P) 0.1 - 999.9℃ (0.1 - 999.9%)
Integral Time (I) 0 to 9999 sec.
Derivative Time (D) 0 to 9999 sec.
Control Period (T) 0.1 to 120.0 sec. (Relay output and SSR output only)
Manual Reset Value 0.0 - 100.0%
Sampling Period 50 ms
Dielectric Strength 2000 VAC 50/60 Hz for 1 min. (between power terminal and input terminal)
Vibration Resistance 0.75mm amplitude at 5 to 55 Hz (1 min. cycle) in X, Y, and Z directions(2 hours)
Relay
Life
Cycle
Mechanical
OUT1/OUT2 : Over 5,000,000 cycles
AL1/AL2
: Over 20,000,000 cycles
(※TK4H/TK4W/TK4L: over 5,000,000 cycles)
Electrical
OUT1/OUT2 : Over 200,000 cycles
AL1/AL2
: Over 100,000 cycles
(※TK4H/TK4W/TK4L: over 200,000 cycles)
Insulation Resistance 100MΩ (at 500VDC megger)
Noise Resistance
Square shaped noise by noise simulator (pulse width 1 ㎲) ± 2 KV R-phase, S-
phase.
Memory Retention Approx. 10 years (non-volatile semiconductor memory type)
Environ
-ment
Ambient
Temperature
-10 to 50℃, Storage temperature: -20 to 60℃
Ambient
Humidity
35 to 85% RH, Storage humidity: 35 to 85% RH
Protection IP65 (front) ※TK4SP: IP50 (front)
Insulation type
※
2
Unit Weight
Approx.
105 g
Approx. 85
g
Approx.
140 g
Approx.
141 g
Approx.
141 g
Approx.
198 g
※1: At room temperature ranges and at all other temperature ranges
 At room Temperature range(23℃ ± 5℃)
 TC K, J, T, N, E type , below -100℃ / TC L, U, PL II type: (PV ±0.3% or ±2℃,
select the bigger one) ± 1Digit
 TC C, G type / TC R, S type bellow 200℃: (PV ±0.3% or ±3℃, select the bigger
one) ± 1 digit
 TC B type, below 400℃: There is no accuracy standard.
