Autonics TK4M User Manual

6 Parameter Settings and Functions
98 © Copyright Reserved Autonics Co., Ltd.
6.7.2 Run/Stop [PAR1 → R-S]
 Users may run or stop control output by force while in Run mode.
 The stop command stops control output. Auxiliary output, however, is not affected by
the command.
 This feature can be enabled by configuring parameters. In addition, the front panel's
digital input keys (▼ and ▲) and digital input terminals (DI-1 and DI-2) can be assigned
to the run/stop feature.
Setting Description
RUN
Forced control output run in Stop mode.
STOP
Forced control output stop in Run mode.
Setting Group Parameter Setting Range Factory Default Unit
PAR1
R-S
RUN
/
STOP
RUN
-
 With stop enabled, the front panel's SV display indicates
STOP
.
 You can change the setting when in the stop state. The stop status will
remain in effect after shutting down the controller and powering it back
on.
 When stop is in effect, STOP MV will be output. In case of a sensor
break occuring while in STOP, STOP MV is output.
 The run/stop setting remains in effect after turning power back on.
 If the Digital Input (, ) feature has been set for RUN/STOP,
RUN/STOP feature by modifying front keys or parameter is unable..
6.7.2.1 Stop Control Output Settings [PAR5 → ST.MV]
This parameter sets the control output value when in the stop state. With ON/OFF control,
select between
100.0 (ON) and 000.0 (OFF). With PID control, the user can adjust the
MV between
000.0 and 100.0.
Setting
Group
Param
eter
Setting Range
Factory
Default
Unit
PAR5
ST.MV
Standard
Control
ON/OFF
Control
000.0
(OFF)/
100.0
(ON)
000.0
%
PID
Control
000.0
to
100.0
000.0
Heating
and
Cooling
Control
ON/OFF
Control
`00.0
(Cooling ON)
/
000.0
(OFF)/
100.0
(Heating ON)
000.0
PID
Control
`00.0
(Cooling) to
100.0
(Heating)
000.0
