6 Parameter Settings and Functions
50 © Copyright Reserved Autonics Co., Ltd.
Input Types Display
Temperature
Range (℃)
Temperature
Range (℉)
JPt 100 Ω 1
JPtH
-200 to 650 -328 to 1202
JPt 100 Ω 0.1
JPtL
-199.9 to 650.0 -199.9 to 999.9
DPt 50 Ω 0.1
DPT5
-199.9 to 600.0 -199.9 to 999.9
DPt 100 Ω 1
DPtH
-200 to 650 -328 to 1202
DPt 100 Ω 0.1
DPtL
-199.9 to 650.0 -199.9 to 999.9
Nickel 120 Ω 1
NI12
-80 to 200 -112 to 392
Analog
Voltage
0 to 10V
AV1
-1999 to 9999
(Decimal point placement is
configurable.)
0 to 5V
AV2
1 to 5V
AV3
0 to
100mV
AMV1
Current
0 to
20mA
AMA1
4 to
20mA
AMA2
※1: C (TT): Same temperature sensor as former W5 (TT).
※2: G(TT): Same temperature sensor as former W (TT).
 Temperature sensors are to convert subject temperature to electrical signals for the
temperature controller allowing it to control output.
 SV (Setting Value) can only be set within the input range.
If SV (Setting Value) is set beyond the input range, values exceeding the
input range are ignored.
