Before You Start
• Your vehicle must be
scanned before viewing the
data. If
DATA is pressed, and
the vehicle has not been
scanned, the scanner will dis-
play
Press the Scan
key to Scan New
Data
. Refer to “Data
Communications Link (DCL)
Scan” on page 33.
The EZ-SCAN scanner DOES NOT
need to be connected to the vehicle
to view the scanned data. The vehi-
cle engine configuration and data will
remain in the scanner’s memory until
a vehicle is scanned again. This
allows you to review the data at a
later time, or to use EZ-PC to load
the data into a computer.
Viewing the DCL Data
1. If the EZ-SCAN scanner is not ON,
press
POWER to display the open-
ing screen.
2. Press DATA to display the Data
menu. Use the arrow keys until
5-DCL Data is highlighted, then
press
ENTER.
3. Information from the DCL comput-
er/sensors in your vehicle
(Operational Data Items) will be dis-
VIEW THE DCL DATA - FORD
Page 43
1-KOEO Codes
2-Memory Codes
3-KOER Codes
4-Clear Codes
5-DCL Data
6-EZ-PC
Engine Speed
643 RPM 01
Spark Advance
10.0
o02
Throttle Posn
3.8 VOLTS 03
1-KOEO Codes
2-Memory Codes
3-KOER Codes
4-Clear Codes
5-DCL Data
6-EZ-PC
