NOTE: Only applies to cars equipped with DCL.
Before You Start
• Use Capture Mode to help diagnose intermittent problems
that occur while driving the vehicle by capturing data before,
during, and after a problem occurs.
CAUTION: AutoXray recommends that the person operating the
vehicle does not use/view the scanner. Always use an assistant to
operate the scanner while driving the vehicle.
Capturing the Problem
1. Make sure the EZ-SCAN scanner cable is out of the driver’s
way, and is correctly connected to the scanner and to the vehi-
cle, then press
POWER.
2. Press MON to display Monitor
menu. Use the arrow keys until
2-DCL Capture is highlighted,
then press
ENTER.
3. Make sure 1-Start Capture
is highlighted, then press ENTER.
4. The screen will display Capture
Mode
and then up to seven ‘>’
symbols. Each ‘>’ symbol repre-
sents a user defined length of
time.
NOTE: When Capture Mode is
started, the scanner will
begin displaying ‘>’ sym-
bols. Each symbol repre-
sents two frames of data.
The default setting for each
DCL DATA CAPTURE - FORD
Page 48
1-Wiggle Test
2-DCL Capture
1-Start Capture
2-View Data
