11. Enter the required information in the appropriate fields, such as Network Passphrase and
Network Passphrase (Again).
This passphrase must match the passphrase used while installing EMS.
See the EMS Appliance Configuration screen field descriptions table.
12. Press Enter.
The system displays the top-level configuration screen.
13. Use the arrow keys to select the Management Interface Setup option, and press Enter.
The system displays the Management Interface Setup for ASBCE screen.
14. Enter the required information in the appropriate fields, such as EMS Server IP Address
(ipv4), and click OK.
For information about the acceptable field entries and field description on the Management
Interface Setup screen, see the Management Interface Setup screen field descriptions table.
15. Use the arrow keys to select the Time Zone option.
The system displays the Configure Time Zone screen.
16. Select the appropriate time zone and click OK.
The system displays the Device Configuration screen.
17. Type the required information and click OK.
Note:
The country code must be of two characters.
The system displays the Device Configuration screen.
18. Use the tab keys to select Back.
The system displays the top-level configuration screen.
19. Use the tab keys to select Done and press Enter.
A script is automatically activated that configures Avaya SBCE with the information provided
in the previous steps.
20. If you have specified an NTP server that cannot be contacted, select one of the following
options to proceed:
• 1-Retry (default)
• 2-Change NTP servers
• 3-Manually configure date and time
21. Set the date manually (if prompted).
22. Set the time manually (if prompted).
23. Enter the password to be used by the root user and press Enter.
24. Enter the same password for the ipcs user and press Enter.
Configuring Avaya SBCE
August 2015 Deploying Avaya SBCE 63
Comments on this document? infodev@avaya.com
