Assembly
AVENTICS | ECS Actuator | R417002911–BDL–001–AA 23
English
Fig. 6: Mounting the Marex ECS Actuator
M8
10 Nm
GND
M8
10 Nm
M8
10 Nm
POWER PROPULSION BUS
