22
Model E1010 Indicator Service Manual
This item is to set the window size for the center-of-zero annunciator. You
can choose between ±¼ and ±½ division. When the weight falls within the
window size, the center-of-zero annunciator lights.
1. Press the UNITS key. . .
C-ZERO is displayed.
2. Press the PRINT key. . .
The current setting is displayed.
3. Toggle between 0.25 and 0.5 by using the UNITS or TARE key and
press the ENTER key to accept the choice. . .
C-ZERO is displayed.
Use this item to enter the serial number for your indicator. This value is used
in some serial outputs and reports for record keeping purposes.
1. Press the UNITS key. . .
SERIAL is displayed.
2. Press the PRINT key. . .
SN-----is displayed briefly followed by the first six digits of the
serial number.
3. Key in the first six digits of the serial number of your indicator and press
ENTER to accept the value or press ESC to view next. . .
-----SN is displayed briefly followed by the current value of the last
three serial number digits.
4. Key in the last three serial numbers of your indicator and press ENTER
to accept the value or press ESC to to return to. . .
SERIAL is displayed.
This completes the SCALE portion of the Service menu. To exit to normal
weighing mode, press the ESC key
OR
Press the SELECT key and continue to the APP submenu covered in the
next section.
C-ZERO
(Center of zero window)
Service Menu—SCALE submenu (continued)
SERIAL
(Serial number entry)
The serial number of your
indicator can be found on the
affixed tag on the outside of the
indicator case.
To Next Page
