Example 4: Single System Expanded I/O (Stage 16s)
Single System Expanded I/O with Up to 48 In/36 Out, 3 Stage 16 IO Racks and 2 AVB Network Cards
With S6L-24C 112-Stage 16 systems, three Stage 16s can be connected as shown below. Connections are identical to Example 3:
Single System Expanded I/O (Stage 64s)
.
1.1
1.2
2
3
4
= Primary audio network connections
= Redundant audio network connections
