IFD500 Series Pilot Guide
4-26 Map Subsystem
NOTE
Weather Source Selection
An IFD can only display weather data from one source
(e.g. SkyTrax100, GDL-69). The supported
provider/device is assigned at time of installation.
For dual IFD installations with more than one type of
weather source, one weather source must be wired to
the first IFD only and the other weather source must be
wired to the second IFD only.
Weather Product
Grouping Title/Category
Possible Selections Within the
Grouping
Datalink radar
Storm Cells
Icing (incl. SLD and Probability)
Winds Aloft
Cloud Tops
Turbulence
Onboard Radar
Datalink lightning
Sensor – Strike
Sensor – Cell
Sensor – Clear Strikes
Selections can be made by either touching the desired product or by
using the bottom right knob.
Note that when there is an on-board lightning sensor selected
(Avidyne TWX670 Tactical Weather System or L3 WX500
Stormscope), the “Lightning” grouping will also include a “Clear
