IFD500 Series Pilot Guide
Aux Subsystem 5-89
specific enablement. Contact Avidyne sales in order to enable
those options.
VID – enable RS-170 external video input, such as that
from an infrared camera. Video will be displayed on the
VIDEO tab in the Map subsystem. Also requires specific
hardware enablement.
RDR – enable digital weather radar display and control
functions. Display and control are accomplished using
the RADAR tab in the Map subsystem.
TAWS – when not coupled with HELO, this option
enables TAWS-B capability.
SVS – standard option on an IFD550 to enable synthetic
vision.
F500 – standard option to enable FLTA with 500 foot
callout.
ENET/IO – standard option to enable WiFi.
16W – enable 16 watt radio. Only available for 28V
aircraft.
SAR – enable search and rescue patterns
BT – standard option to enable Bluetooth.
HELO – enable helicopter operations (aircraft symbol,
database procedures). When coupled with the TAWS
option, the IFD performs HTAWS functions.
GLAS – enable GPS Legacy Avionics Support for
business jet class aircraft
PORTS – enables a feature that allows use of a WiFi
connected ADS-B input device (e.g. Stratus 3). The
feature will only be operational if the IFD is not configured
to receive traffic/weather from a wired sensor and the
Maintenance Mode option for Capstone portables is
enabled.
