IFD500 Series Pilot Guide
2-10 SVS Subsystem
Yellow or red highlighted obstacles on the SynVis scene will also
display the MSL altitude of the obstacle top.
Depiction of non-threat obstacles in the SynVis scene is governed
in part by the Setup Page selections for the map. If obstacle
filtering is disabled on the Setup Page, then all obstacles within
12nm will be displayed in the SynVis scene. If obstacle filtering is
enabled, then the system will display the greater of 2000’ or the
selected altitude filtering number. For example, if 500’, 1000’ or
1500’ were selected on the Setup Page for low obstacle altitude
filtering, the system will depict all obstacles within 2000’ vertical
feet of the aircraft out to 12nm in the SynVis scene.
NOTE
When both obstacles and terrain are potential
threats, it is possible that the display will show both
yellow and red. However, the CAS message will be
clear regarding the most imminent threat (e.g.
Warning Obstacle vs. Warning Terrain).
