Pendant Mount Installation
Required Tools and Materials
l
Small slotted screwdriver with 5/64” or 2 mm blade width — for connecting power when not using
Power over Ethernet.
l
Pendant wall mount (WLMT-1021) or Pendant NPT pipe mount
o
(Pendant wall mount only) No. 2 Phillips screwdriver — for attaching the pendant wall mount
bracket to a mounting surface
o
(Pendant NPT pipe mount only) 1-1/2” NPT-female to NPT-female pipe adapter — for attaching
the pendant NPT mount to a pipe
l
Silicone sealant
Package Contents
Ensure the package contains the following:
Note: The pendant wall mount and pendant NPT mount are sold separately.
l
Avigilon H6A Dome Surface Mount Camera
l
Mounting template sticker
l
Cable entry grommets
l
RJ-45 grommet piercing cap
l
4 screws and anchors for solid walls
l
Pendant NPT mount:
o
Lock nut
o
Thread seal tape
l
Pendant Wall Mount:
o
Mounting template sticker
o
Mounting bracket
o
Thread seal tape
o
Four screws and anchors for solid walls
Installation Steps
Complete the following sections to install the device.
Pendant Mount Installation 28
