In-Ceiling Mount Installation
Required Tools and Materials
l
Small slotted screwdriver with 5/64” or 2 mm blade width — for connecting power when not using
Power over Ethernet.
l
No. 2 Phillips screwdriver — for attaching the camera to a mounting surface and positioning the
clamps.
Camera Package Contents
Ensure the package contains the following:
l
Avigilon H6A Indoor Dome Camera
l
Mounting template sticker
l
Cable entry grommets
l
RJ-45 grommet piercing cap
l
4 screws and anchors for solid walls
Installation Steps
Complete the following sections to install the device.
Mounting the Dome Camera Using the Ceiling Clamps
CAUTION — This camera is designed for indoor use only.
Perform the following steps if you will be mounting the camera into a ceiling.
In-Ceiling Mount Installation 21
