4. Attach the lanyard on the pendant mount to the lanyard hook on the bottom of the surface mount
adapter.
5. Mount the surface adapter so the mounting screws go into the holes and then twist the surface
adapter clockwise until it is secure. Use a screwdriver to tighten the screws on the inside of the
adapter, and secure the adapter to the wall arm.
6. Install the sealing grommet with all the required cables. For more information, see Inserting Cables
through the Sealing Grommet on page11.
7. Connect the lanyard in the adapter to the lanyard hook on the bottom of the camera. Allow the camera
to hang.
8. Tighten the bolts to secure the camera to the adapter.
Mounting the Dome Camera to the Pendant Wall Mount 35
