(Optional) Installing the NPT Mount Adapter
CAUTION — The dome camera must be mounted as instructed below or problems with moisture may
arise and will not be covered by the dome camera warranty.
If you are installing the H4 Multisensor camera with an NPT adapter (IRPTZ-MNT-NPTA1), the dome camera must
be mounted on a 1-1/2” NPT female threaded wall or ceiling mounting bracket. The mounting bracket is not
included in the camera package.
1.1. Wrap the thread of the NPT adapter with the supplied thread-sealing tape to create a water tight seal
around the camera connection. There should be three to five turns around the entire threaded surface.
When applying the thread-sealing tape, wrap the tape clockwise.
This will ensure the tape does not unravel when installing the mating parts together.
Tip: Always apply thread-sealing tape to threaded mounts to help prevent the threads from binding.
(Optional) Installing the NPT Mount Adapter 18
