Avigilon H4A Series User Manual

Connection Status LED Indicator
Once connected to the network, the Connection Status LED indicator will display the progress in connecting to
the Network Video Management software.
The following table describes what the LED indicator shows:
Connection State Connection Status
LED Indicator
Description
Obtaining
IPAddress
One short flash
every second
Attempting to obtain an IP address.
Discoverable Two short flashes
every second
Obtained an IPaddress but not connected to the NetworkVideo
Management software.
Upgrading Firmware Two short flashes
and one long flash
every second
Updating the firmware.
Connected On Connected to the Network Video Management software or an
ACC Server. The default connected setting can be changed to
Off using the camera's web user interface. For more information
see the Web Interface User Guide — Avigilon High Definition
H.264 IP Cameras.
Connection Status LEDIndicator 62

Avigilon H4A Series Specifications

General

Impact Rating	IK10
Day/Night	Yes
Video Compression	H.264
Ingress Protection	IP66
IR Distance	Up to 30m (98ft)
Wide Dynamic Range (WDR)	Yes, up to 120dB
Frame Rate	Up to 30fps
Power	PoE (IEEE 802.3af)
Minimum Illumination	0.05 lux (color)
Audio Support	Yes
