Pendant Mount Installation
Camera Package Contents
The H4 Multisensor camera has a variety of different mounting, dome cover, camera and accessory options. The
components for each H4 Multisensor camera will arrive in a camera package, a dome cover package, a
mounting adapter package, a mount package (for pendant mount cameras), and an optional IR Ring package.
Ensure the camera package contains the following:
l Avigilon H4 Multisensor Camera module. A 3- or 4-sensor camera module with 3 MP, 5 MP, or 4K (8 MP)
resolution per sensor.
l Audio, external power, and I/O pigtail cable connector
l RJ45 CAT5E plugs (x2)
l RJ45 connector waterproof gland
Ensure the Pendant mount adapter package contains the following:
l Pendant mount adapter (H4AMH-AD-PEND1)
l Installation instructions sheet
If you are installing the camera with the pendant wall mount, ensure the package includes the following:
l Pendant wall mount (IRPTZ-MNT-WALL1)
l Mounting template sticker
If you are installing the camera with the NPT mount, ensure the package includes the following:
l NPT mount (IRPTZ-MNT-NPTA1)
l Lock nut
l Thread sealing tape
Ensure the dome cover package contains the following:
l Clear or smoked dome bubble and cover (H4AMH-DO-COVR1 or H4AMH-DO-COVR1-SMOKE)
If you are installing the camera with the optional IR illuminator, ensure the package includes the following:
l Optional IR illuminator ring (H4AMH-AD-IRIL1)
Installation Steps
Complete the following sections to install the device.
(Optional) Installing the Pendant Wall Mount
Use the procedure below to install the pendant wall mount (IRPTZ-MNT-WALL1) for use with the H4 Multisensor
pendant mount adapter (H4AMH-AD-PEND1).
Pendant Mount Installation 15
