Surface Mount Installation
Camera Package Contents
The H4 Multisensor camera has a variety of different mounting, dome cover, camera and accessory options. The
components for each H4 Multisensor camera will arrive in a camera package, a dome cover package, a
mounting adapter package, a mount package (for pendant mount cameras), and an optional IR Ring package.
Ensure the camera package contains the following:
l Avigilon H4 Multisensor Camera module. A 3- or 4-sensor camera module with 3 MP, 5 MP, or 4K (8 MP)
resolution per sensor.
l Audio, external power, and I/O pigtail cable connector
l RJ45 CAT5E plugs (x2)
l RJ45 connector waterproof gland
Ensure the Surface mount adapter package contains the following:
l Surface mount adapter (H4AMH-AD-DOME1)
l Installation instructions sheet
l Mounting template sticker
Ensure the dome cover package contains the following:
l Clear or smoked dome bubble and cover (H4AMH-DO-COVR1 or H4AMH-DO-COVR1-SMOKE)
If you are installing the camera with the optional IR illuminator, ensure the package includes the following:
l Optional IR illuminator ring (H4AMH-AD-IRIL1)
Installation Steps
Complete the following sections to install the device.
Installing the Surface Mount Adapter
Follow this procedure to route camera cables and install the surface mount adapter (H4AMH-AD-DOME1) to the
mounting surface.
1. Determine where the cables will enter the camera. The surface mount adapter has two cable entry holes:
one on the side and one on the bottom of the mounting adapter.
l Use the supplied closure plug to fill the unused cable entry hole.
l When installing outdoors, wrap the threads of the closure plug with plumber's tape to create a
watertight seal.
NOTE: Only use vandal-resistant conduits to route cables into the mounting adapter. Vandal-resistant
conduits will protect the cables and compliment the camera's vandal-resistant design.
Surface Mount Installation 32
