AVM FRITZ!Box 7360 User Manual

118
The User Interface Does Not Open
5. Click the “Internet / DSL Information” menu and select
the “Line Setting” tab. In the “Annex Settings” section,
make sure that the annex working on your DSL line is
set. Save your settings by clicking “Apply”.
After the annex setting has been changed, the FRITZ!Box re-
starts automatically. The connection to the DSL network has
been established as soon as the “Power / DSL” LED stops
flashing and remains lit up.
18.2 The User Interface Does Not Open
If an error message is returned when you open the FRITZ!Box
user interface, this can have various causes. Check the
causes listed below and attempt to resolve the error.
Restarting the FRITZ!Box
The user interface cannot be opened or does not react.
Inconsistencies within the FRITZ!Box.
1. Restart the FRITZ!Box.
Remove the power cable from the outlet.
2. Wait about five seconds before reconnecting to the pow-
er supply.
3. To make sure that the FRITZ!Box has finished restarting,
wait until the “Power / DSL” LED lights up and stops
flashing and, if you have switched on WLAN, the “WLAN”
LED remains lit up as well. This ensures that the
FRITZ!Box restart has been completed.
4. Try again to open the FRITZ!Box user interface by enter-
ing fritz.box
in the address field.
Cause
Help
FRITZ!Box_7360-en.fm Seite 118 Mittwoch, 15. Februar 2012 5:21 17

AVM FRITZ!Box 7360 Specifications

General

Plug and Play	Yes
Internal memory	512 MB
RJ-11 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Bandwidth	2.4 GHz
Rack mounting	No
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Frequency range	2.4 - 2.4835 GHz
Power supply type	DC/11W
Dimensions (WxDxH)	226 x 159 x 47 mm
USB connector type	USB Type-A
WLAN data transfer rates supported	300 Mbit/s
Cables included	LAN (RJ-45), Phone (RJ-11)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Firewall security	IPv6
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2
Power supply	11 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	8 W
Product color	Red

Weight and Dimensions

Depth	159 mm
Width	226 mm
Height	47 mm
Weight	- g
