AVM FRITZ!Box 7360 User Manual

124
Cannot Establish a WLAN Connection
18.3 Cannot Establish a WLAN Connection
If you are not able to establish a WLAN connection between
your computer and the FRITZ!Box, then please undertake the
following measures to seek the source of the error and re-
solve it.
Enabling the WLAN Device
The WLAN device cannot find a wireless network.
The WLAN device is not ready for operation.
Make sure that the WLAN device is ready for operation. Some
of the WLAN devices installed in notebooks must be activated
by flipping a switch on the notebook.
Enabling WLAN
The wireless network of the FRITZ!Box is not found by the
WLAN device.
WLAN is not enabled in the FRITZ!Box. If the “WLAN” LED on
the FRITZ!Box is not lit up or is flashing, this means that WLAN
is not enabled.
Press the WLAN button on the FRITZ!Box. The “WLAN” LED
begins flashing and then lights constantly. This means that
the WLAN function is enabled.
Cause
Help
For questions on the WLAN device of your computer, please
contact the manufacturer.
Cause
Help
FRITZ!Box_7360-en.fm Seite 124 Mittwoch, 15. Februar 2012 5:21 17

AVM FRITZ!Box 7360 Specifications

General

Plug and Play	Yes
Internal memory	512 MB
RJ-11 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Bandwidth	2.4 GHz
Rack mounting	No
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Frequency range	2.4 - 2.4835 GHz
Power supply type	DC/11W
Dimensions (WxDxH)	226 x 159 x 47 mm
USB connector type	USB Type-A
WLAN data transfer rates supported	300 Mbit/s
Cables included	LAN (RJ-45), Phone (RJ-11)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Firewall security	IPv6
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2
Power supply	11 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	8 W
Product color	Red

Weight and Dimensions

Depth	159 mm
Width	226 mm
Height	47 mm
Weight	- g
