AVM FRITZ!Box 7360 User Manual

66
WLAN Standards
WLAN base stations. Each client can then automatically
register at the WLAN base station with the best availabil-
ity.
• Each IP address may be assigned only once in the wire-
less network.
11.5 WLAN Standards
The Institute of Electrical and Electronic Engineers (IEEE) de-
fined the WLAN standards IEEE 802.11b, IEEE 802.11g,
IEEE 802.11n and IEEE 802.11i.
The IEEE 802.11b, IEEE 802.11g and IEEE 802.11n standards
define the throughput rate within a wireless radio network.
IEEE 802.11i is a security standard.
Standards for the Throughput Rate
Data Throughput
The throughputs listed differentiate between gross and net
transmission rates. The net speed describes the transmission
rate of the user data.
The FRITZ!Box supports your choice of the standards
IEEE 802.11b, IEEE 802.11g and IEEE 802.11n. WLAN devices
based on one or more of the standards listed can be used for
WLAN connections with the FRITZ!Box.
IEEE 802.11b
With a maximum throughput rate of 11 Mbit/s, this is the old-
est WLAN standard. Older WLAN devices of the first genera-
tion can communicate with the FRITZ!Box using 802.11b.
However, if the WLAN device supports newer standards such
as 802.11g, the latest standard should be used.
Standard Frequency Band Gross Data Throughput up
to
Net Data Throughput up to
802.11b 2.4 GHz 11 Mbit/s 5 Mbit/s
802.11g 2.4 GHz 54 Mbit/s 25 Mbit/s
802.11n 2.4 GHz 300 Mbit/s 150 Mbit/s
FRITZ!Box_7360-en.fm Seite 66 Mittwoch, 15. Februar 2012 5:21 17

AVM FRITZ!Box 7360 Specifications

General

Plug and Play	Yes
Internal memory	512 MB
RJ-11 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Bandwidth	2.4 GHz
Rack mounting	No
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Frequency range	2.4 - 2.4835 GHz
Power supply type	DC/11W
Dimensions (WxDxH)	226 x 159 x 47 mm
USB connector type	USB Type-A
WLAN data transfer rates supported	300 Mbit/s
Cables included	LAN (RJ-45), Phone (RJ-11)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Firewall security	IPv6
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2
Power supply	11 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	8 W
Product color	Red

Weight and Dimensions

Depth	159 mm
Width	226 mm
Height	47 mm
Weight	- g
