AVM FRITZ!Box 7360 User Manual

Increasing the Range of the WLAN Connection
65
WDS: Expanding the WLAN range using a WDS repeater
Note the following for WDS configuration:
• All WLAN base stations implemented in the WDS must
support WDS and be configured for this technology.
• All WLAN base stations implemented as repeaters in the
WDS must be located within the radio range of the WDS
base station.
• The FRITZ!Box can function as a WDS base station to es-
tablish the Internet connection for other WDS repeaters,
or as a WDS repeater to expand the range of a WDS base
station.
• All WDS connections between the WDS base station and
the WDS repeaters must be secured using the same en-
cryption (e.g. WPA/WPA2). Note that the WPA2 encryp-
tion method is available only when your network con-
sists of AVM devices, since in the WLAN standard only
WEP encryption has been specified for WDS connec-
tions.
• All WLAN base stations in the WDS must use the same
radio channel.
• Every WLAN base station participating in the WDS fulfills
the tasks of a WLAN access point for its WLAN clients.
This means that the WLAN clients see each WLAN base
station with an individual name (SSID) and individual
encryption settings.
If you use the WLAN control software provided in
Windows 7, Windows Vista or by the Windows XP Ser-
vice Pack 2 on your WLAN clients, you can assign the
same SSID and the same encryption settings to different
FRITZ!Box (base station)Repeater
Power
supply
Power
supply
DSL
Festnetz
Internet
WLAN
INFO
Power/DSL
FRITZ!Box_7360-en.fm Seite 65 Mittwoch, 15. Februar 2012 5:21 17

AVM FRITZ!Box 7360 Specifications

General

Plug and Play	Yes
Internal memory	512 MB
RJ-11 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Bandwidth	2.4 GHz
Rack mounting	No
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Frequency range	2.4 - 2.4835 GHz
Power supply type	DC/11W
Dimensions (WxDxH)	226 x 159 x 47 mm
USB connector type	USB Type-A
WLAN data transfer rates supported	300 Mbit/s
Cables included	LAN (RJ-45), Phone (RJ-11)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Firewall security	IPv6
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2
Power supply	11 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	8 W
Product color	Red

Weight and Dimensions

Depth	159 mm
Width	226 mm
Height	47 mm
Weight	- g
