Guest Access: WLAN Connection for Guests
61
If your WLAN adapter supports WPA, but not WPA2:
Enable WPA encryption.
Select the WPA mode “WPA (TKIP)” or “WPA+WPA2”.
Replace the WPA network key with a new, unique value.
If your WLAN adapter supports neither the WPA nor the WPA2
mechanism:
Enable WEP encryption.
Replace the WLAN key with a new, unique value.
Wireless Network Name (SSID)
In the factory settings of the FRITZ!Box, the name of the wire-
less network (SSID) is set to “FRITZ!Box 7360”.
11.2 Guest Access: WLAN Connection for Guests
You can connect computers with the FRITZ!Box via WLAN so
that they can access the Internet without being integrated in
the home network of the FRITZ!Box. This function is called
“guest access”.
Your guests can use the guest access, for instance, to surf the
web with a notebook and to receive e-mail.
Prerequisites for Guest Access
The FRITZ!Box must be connected directly to the DSL line.
We strongly recommend the use of a WLAN device that sup-
ports WPA or WPA2. WEP is out of date and data encrypted
with WEP can be deciphered within minutes.
It may occur that an additional device with the same
FRITZ!Box network name is located in the vicinity of your
FRITZ!Box. Therefore we recommend changing the preset ra-
dio network name.
FRITZ!Box_7360-en.fm Seite 61 Mittwoch, 15. Februar 2012 5:21 17

Table of Contents

Other manuals for AVM FRITZ!Box 7360

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the AVM FRITZ!Box 7360 and is the answer not in the manual?

AVM FRITZ!Box 7360 Specifications

General IconGeneral
Plug and PlayYes
Internal memory512 MB
RJ-11 ports quantity2
Ethernet LAN (RJ-45) ports4
Bandwidth2.4 GHz
Rack mountingNo
Ports quantityThe number of ports or external interfaces to which other equipment can be connected.
Frequency range2.4 - 2.4835 GHz
Power supply typeDC/11W
Dimensions (WxDxH)226 x 159 x 47 mm
USB connector typeUSB Type-A
WLAN data transfer rates supported300 Mbit/s
Cables includedLAN (RJ-45), Phone (RJ-11)
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 4 (802.11n)
Firewall securityIPv6
Security algorithms128-bit WEP, 64-bit WEP, WPA, WPA2
Power supply11 W
AC input voltage230 V
AC input frequency50 Hz
Power consumption (typical)8 W
Product colorRed
Weight and Dimensions IconWeight and Dimensions
Depth159 mm
Width226 mm
Height47 mm
Weight- g
