6 HMX Extender System Installer/User Guide
Figure 1.1: HMX Workstation Extension System - Desktop Mode
Safety Precautions
To avoid potential video and/or keyboard problems when using Avocent products:
• If the building has 3-phase AC power, ensure that the workstation and monitor are on the same
phase. For best results, they should be on the same circuit.
Table 1.1: Figure 1.1 Descriptions
Number Description
1 Rack Mounted
Computer and
Transmitter
2 Gigabit Ethernet
Switch
3 HMX Manager
4 User Station
5 Ethernet LAN
