Chapter 3: Operations 29
4. If the user has access to more than one target computer, then the list of target computers is
presented.
5. Click the Connect button to establish a connection.
Configuring networking parameters using the OSD
The OSD enables you to set the IP address, Netmask and Default gateway for the user station and
the transmitter that is connected. This feature would normally be used when configured for
Extender Mode.
To change networking information for the user station and transmitter:
1. Press Print Screen and select the Net tab to configure network parameters for your HMX user
station or transmitter.
Figure 3.5: Network Config Menu (Receiver)
2. To change the user station network configuration, select Rcvr from the Network Config menu
and fill out the desired information.
- or -
To change the transmitter network configuration, select Trans from the Network Config menu
and fill out the desired information.
3. Click Apply to save the changes.
Setting the OSD timeout
The amount of time the OSD is displayed on the monitor is configurable.

